PHD 951A0025EG FIG 951N Insert Nut, 1/4 in Rod, Low Carbon Steel, Electro-Galvanized, Domestic
Sku #84874302571
MFG #951A0025EG
Attributes
| Series: | FIG 951N |
| Thickness: | 1/4 in |
| Finish: | Electro-Galvanized |
| Rod Diameter: | 1/4 in |
| Material: | Low Carbon Steel |
| Domestic/Import: | Domestic |
- ASTM B633 SC1 and SC3|BAA Compliant
- Designed to be embedded in concrete to provide a means of suspending pipe from ceilings
- The insert is held in place by nailing it to the forms, until the concrete is poured
- The insert comes with a snap-out plug to keep the inner housing clean during pouring of the concrete
- After the concrete has set, the plug is removed, exposing the inner housing
- The rod should be tightened until it touches the top of the insert, but should not be forced further to avoid damage to the insert
