Sku #78656408709
MFG #10ATCPBK
Attributes
| Type: | Multi-Service Pre-Wired Recessed |
| Hole Size: | 10 in |
| Capacity: | 19 cu-in, 14 cu-in |
| Series: | Evolution™ 10AT |
| Number of Gangs: | 8 |
| Device Type: | Fire-Rated |
- Commercial, Office, Education, Hospitals, Government Buildings, Schools, Universities, Commercial Kitchen, Wet/Dry Locations Applications
- Largest capacity poke-thru devices on the market - the 10AT series is designed for a 10 in core hole and provides up to eight gangs of power, communication and/or A/V capability
- Internal wiring capacity - Evolution™ series 10 in poke-thru devices are the first in the industry with the capacity to accommodate wiring connections inside the unit, eliminating the need for an external junction box and making future moves, adds and changes faster and easier
- Step-on-it installation - quick and easy installation without the need for additional fasteners or a second installer
- Auto-close sliding egress doors egress doors lock in position when open and automatically close around cables, reducing the egress opening to the smallest size possible
- Stronger hinge - new design features an improved, stronger hinge with a more fluid opening and closing motion
- 2 hr fire classified
- All devices are recessed 4-1/2 in below the finished floor level
- Cover and stem are pre-assembled together
- https://www.youtube.com/watch?v=l7APLxPMtO8
- ARRA Compliant|Buy American Act Compliant|cULus Listed File No. E2961 Guide QCIT|cULus Listed File No. R8209 Guide CEYY|Article No. 300.21, 300.22 314 NEC|ADA Standard 4.5|RoHS Compliant
- (2) Proprietary 68DB Device Bracket, (2) 10PTHA Outer Pass-Through Plate, (4) 1PTHA Center Pass-Through Plate, (1) 10BLH Outer Blank Plate, (1) 1075CHA Service Feed Plate
