Square D™ MJL26350 Molded Case Circuit Breakers

Documents

Square D™ PowerPact™ MJL26350 80% Rated Molded Case Circuit Breaker, 600 V AC, 350 A, 100 kA at 240 V AC/65 kA at 480 V AC/25 kA at 600 V AC Interrupt, 2 Poles, Electronic Trip

Sku #78590187980

MFG #MJL26350

Attributes

Type:	80% Rated
Amperage Rating:	350 A
Interrupt Rating:	100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC

Voltage Rating:	600 V AC
Frequency Rating:	50/60 Hz
Frame:	M Frame

For providing overload and short circuit protection

Available in 2 or 3 pole design
Standard 80% rating only
Common mounting holes, handle locations, and trim dimensions
Wide range of field installable accessories

UL 489 File No. E10027|CE Certified|CSA C22.2 File No. 5-02 File No. LR7551|NMX J-266|IEC 60947-2|Federal Specification W-C-375B|PROP65: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov|RoHS Compliant

Documents

Square D™Square D™ PowerPact™ MJL26350 80% Rated Molded Case Circuit Breaker, 600 V AC, 350 A, 100 kA at 240 V AC/65 kA at 480 V AC/25 kA at 600 V AC Interrupt, 2 Poles, Electronic Trip

SKU #78590187980

MFG #MJL26350
