Square D™ I-Line™ LH36125 Adjustable High Interrupt Molded Case Circuit Breaker, 600 V AC/250 V DC, 125 A, 65 kA at 240 VAC/35 kA at 480 VAC/25 kA at 600 VAC/50 kA at 125/250 VDC Interrupt, 3 Poles, Thermal Magnetic Trip
Sku #78590185437
MFG #LH36125
Attributes
| Type: | Adjustable High Interrupt |
| Amperage Rating: | 125 A |
| Interrupt Rating: | 65 kA at 240 VAC/35 kA at 480 VAC/25 kA at 600 VAC/50 kA at 125/250 VDC |
| Voltage Rating: | 600 V AC/250 V DC |
| Frequency Rating: | 50/60 Hz |
| Frame: | LH Series |
- Construction, Commercial Buildings, Oil, Gas, Industrial Buildings, Water Wastewater and Data Center Applications
- Protects electrical systems from damage caused by overloads, short circuits, and ground faults
- Automatically opens a circuit under overload or short circuit conditions
- Equipped with Push-To-Trip allows the circuit breaker to be manually tripped without exposure to live parts
- Reliable protection for enclosures, panelboards, switchboards, starters and motor control centers
- RoHS Compliant|UL 489|CSA Certified|CE Marked|Green Premium|PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65Warnings.ca.gov
