Square D™ PowerPact™ MJP36800 Molded Case Circuit Breaker, 600 V AC/250 V DC, 800 A, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/250 VDC/600 VAC Interrupt, 3 Poles, Electronic Trip
Sku #78590178591
MFG #MJP36800
Attributes
| Voltage Rating: | 600 V AC/250 V DC |
| Frequency Rating: | 50/60 Hz |
| Frame: | M |
| Amperage Rating: | 800 A |
| Interrupt Rating: | 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/250 VDC/600 VAC |
| Trip Type: | Electronic |
- Available in 2 or 3 pole design
- Standard 80% rating only
- Common mounting holes, handle locations, and trim dimensions
- Wide range of field installable accessories
- For providing overload and short circuit protection applications
- RoHS Compliant|UL 489 File No. E10027|CE Certified|CSA C22.2 No. 5-02 File No. LR7551|NMX J-266|IEC 60947-2|Federal Specification W-C-375B|PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
