Square D™ 9007C52F Heavy Duty Linear Plunger Actuated Limit Switch, 600 V AC/DC, 10 A, Spring Return Side Roller Plunger with Vertical Roller Actuator, 1NO-1NC Contact, 1 Pole
Sku #78590178344
MFG #9007C52F
Attributes
| Type: | Heavy Duty Linear |
| Voltage Rating: | 600 V AC/DC |
| Contact Configuration: | 1NO-1NC |
| Series: | 9007C |
| Amperage Rating: | 10 A |
| Contact Rating: | 1.2 A at 600 V AC/0.1 A at 600 V DC |
- CSA C22.2 File No. 14|CE Marked|CENELEC|EN 60204-1|IEC 60204-1|EN 50041/EN 609475-1|IEC 609475-1|IEC 60068-2-6|IEC 60068-2-27|IEC 60529|IEC 61140|RoHS Compliant|UL 508|PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP) which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
- Linear movement of operating head
- Form Z, snap action silver contacts
- Without positive opening
- 1.2 A at 600 VAC for A600 NEMA, 1.5 A at 480 VAC for A600 NEMA, 3 A at 240 VAC for A600 NEMA, 6 A at 120 VAC for A600 NEMA, 0.1 A at 600 VDC for Q600 NEMA, 0.27 A at 250 VAC for Q600 NEMA, 0.55 A at 125 VDC for Q600 NEMA
- For material handling such as mechanical conveying, automotive, machine tool and packaging
