Square D™ PowerPact™ JGL36250U33X 80% Rated J Molded Case Circuit Breaker, 600 V AC, 250 A, 65 kA at 240 V AC/35 kA at 480 V AC/18 kA at 600 V AC/20 kA at 250/500 VDC Interrupt, 3 Poles, Electronic Trip

Sku #78590150682

MFG #JGL36250U33X

Attributes

Type:	80% Rated
Amperage Rating:	250 A
Interrupt Rating:	65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC

Voltage Rating:	600 V AC
Frequency Rating:	50/60 Hz
Frame:	J Frame

Available in 2 or 3 pole design
Overcurrent protection and switching on AC systems
Common accessories across the range
Easy to install, extremely versatile, a wide variety of terminal options
https://www.youtube.com/watch?v=ja3DCvAs9M4

Construction, Commercial Buildings, Oil, Gas, Control Equipment Panels, Marine, Industrial Buildings, Water Wastewater, OEM Commercial, Healthcare Facilities, Data Centers, Educational Campuses and Industrial Markets
