Square D™ I-Line™ LAL362501021 Molded Case Circuit Breaker, 600 V AC/250 V DC, 250 A, 42 kA at 240 VAC/30 kA at 480 VAC/22 kA at 600 VAC/10 kA at 125/250 VDC Interrupt, 3 Poles, Thermal Magnetic Trip
Sku #78590133946
MFG #LAL362501021
Attributes
| Voltage Rating: | 600 V AC/250 V DC |
| Frequency Rating: | 50/60 Hz |
| Frame: | L Frame |
| Amperage Rating: | 250 A |
| Interrupt Rating: | 42 kA at 240 VAC/30 kA at 480 VAC/22 kA at 600 VAC/10 kA at 125/250 VDC |
| Trip Type: | Thermal Magnetic |
- Panelboards and Switchboards Applications
- For manual circuit open or automatic current interruption for overload or short circuit conditions
- Flexible platform for various types of mounting and terminations
- Push-to-Trip allows the circuit breaker to be manually tripped without exposure to live parts
- Unit mount and I-Line construction available
- UL 489 File No. E10027|CSA C22.2 File No. 5-02 File No. LR7551|IEC 60947-2|Federal Specification W-C-375B|PROP65: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov|RoHS Compliant
