Pass & Seymour® AF202DFI radiant® Dead Front Tamper Resistant AFCI Receptacle, 125 VAC, 20 A, 2 Poles, Ivory
Sku #78500712793
MFG #AF202DFI
Attributes
| Type: | Dead Front Tamper Resistant |
| Voltage Rating: | 125 V AC |
| Frequency Rating: | 60 Hz |
| Series: | radiant® |
| Amperage Rating: | 20 A |
| Number of Poles: | 2 |
- Protects against fire caused by arc-fault occurrences
- Unlike breaker alternatives, AFCI outlets make it easier to fix trips with a convenient reset button on the outlet
- Test and rest buttons located on face of device at point of use, making it easier to fix trips directly on the device
- SafeLock Protection feature - if critical components are damaged and protection is lost, power to the receptacle is disconnected
- Extends GFCI protection to "downstream" outlets when used with feed-thru wiring configuration
- Note - Will cut power to face and downstream outlets if wired incorrectly
- Auto-ground clip assures a positive ground to a metal box
- Dead front rated as 1 1/2 HP motor control switch
- Easier installation than breakers, fits any wall box, no need to match brand of breaker box
- https://www.youtube.com/watch?v=szTK_AGf_1I&feature=youtu.be
- Residential and Commercial Applications
- RoHS Compliant|ECCN EAR99 UL File No. E363109|CSA Certified|Federal Specification WC596|cULus Listed|FSUL Listed|UL Listed
