Pass & Seymour® 1597TRNAGRY TradeMaster® Duplex Self-Test Tamper-Resistant GFCI Receptacle With Matching TP Wall Plate, 125 V AC, 15 A, 2 Poles, Gray
Sku #78500704984
MFG #1597TRNAGRY
Attributes
| Type: | Duplex Self-Test Tamper-Resistant |
| Voltage Rating: | 125 V AC |
| Frequency Rating: | 60 Hz |
| Series: | TradeMaster® |
| Amperage Rating: | 15 A |
| Number of Poles: | 2 |
- Protects children patented shutter system helps prevent improper insertion of foreign objects meeting National electrical Code® tamper resistant requirements
- Thinner than competitors' GFCI Receptacles, leaves more room for wires in the box
- Auto ground clip assures a positive ground to metal box
- Prevents line load reversal miswire no power to the face or downstream receptacles if wired incorrectly
- Exceeds UL 943 voltage surge requirements, survives 100x the required UL 3 kA/6 kV voltage surge test cycles
- WR models listed to the weather resistant supplement of UL498, meet demanding UL requirements
- Trip indicator light (red LED)
- Side or internal screw pressure plate back wire with 10 to 14 AWG solid or stranded copper wire and 2-back wire holes per terminal
- Ground screw has back wire clamp for easy installation
- 10 kA short circuit rating
- Mounting screws are shipped captive in the device and wall plate for easier installation
- Extra long strap
- Button colors match the device face
- Dual direction test and reset buttons
- 5 +/- 1 m trip threshold
- Industrial, Retail, Health Care, Office, Education, Hospitality/Lodging, Institutional and Multiple Dwelling Applications
- ECCN EAR99|cULus File No. E42190|UL498|UL943|Federal Specification WC596|CSA C22.2 No. 42/144|NEMA WD1/WD6|NAFTA Compliant
