Pass & Seymour® 26252CD Decorator Duplex Dual Controlled Plug Load Straight Blade Receptacle, 125 V AC, 15 A, Brown
Sku #78500703288
MFG #26252CD
Attributes
| Type: | Decorator Duplex Dual Controlled Plug Load |
| Amperage Rating: | 15 A |
| Grade: | Specification |
| Voltage Rating: | 125 V AC |
| NEMA Rating: | NEMA 5-15R |
| Temperature Rating: | -40 to 60 deg C |
- Controlled receptacle marking pad printed on the face of receptacle for superior abrasion resistance
- CH versions feature a factory broken split circuit tab allowing you to control half of the receptacle
- Can be used to control loads using the Wattstopper DLM system and other building control systems
- Corrosion-resistant, plated steel strap locked into assembly to prohibit strap from bending away from body
- One-piece, brass, triple-wipe power contacts for lasting retention
- Heavy-duty compact design for easier installation and long lasting performance
- Impact-resistant nylon face
- Terminal compartments isolated from each other for positive conductor containment
- Side and internal screw-pressure-plate back wire accepts 14 - 10 AWG solid or stranded wire
- All devices fit standard 26 opening wall plate
- cUL File No. E140596|cULus Listed|Federal Specification Specified|UL 498
