Sku #78456757535
MFG #U055C010P
Attributes
| Voltage Rating: | 120/240 V AC |
| Phase: | 1 |
| Circuit Breaker Type: | THQL1120/THQL2150 |
| Amperage Rating: | 70 A |
| Receptacle Type: | BR54U/5-20R2 GFCI |
| Wire Size: | 14 to 8 AWG, 14 to 1/0 AWG |
- Rolled edge door for cord protection
- Continuous duty meter socket with meter guides and reinforced jaws - ringless and ring type
- Utility accepted meter sealing accommodations
- G90 galvanized steel construction for superior corrosion resistance
- Durable polyester powder coat finish resists chipping and fading
- All GFCI duplexes are listed as weather resistant and tamper resistant as required by NEC in Article 406.8 and 406.11
- Dead front construction prevents accidental contact with live parts
- Padlock provision to prevent unauthorized access
- All components factory wired and assembled, reducing installation time
- Door removable for installation ease, stay open position for user convenience
- All terminals accept copper or aluminum wire for added installation flexibility
- Wide range of receptacle configurations
- Broad range of concentric knockouts to accommodate varied wiring needs
- All units with factory installed copper/aluminum equipment ground lug
- Available with GFI circuit breakers
- Eliminates construction delays due to red tag code violations
- All ringless meter socket models have standard horn bypass
- 14 to 8 AWG solid/14 to 1/0 AWG stranded copper, 12 to 8 AWG solid/12 to 1/0 AWG stranded aluminum line connector, 14 to 10 AWG solid/stranded copper load connector
- Circuit Breakers, Receptacles and Meter Socket
- ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL/cUL Listed|NEC Article 406.8 and 406.11
