- Rated as service equipment (panelboard #67 and meter sockets #414)
- Units supplied with factory installed main breakers rated 22 kA IC where applicable
- Load centers are provided with copper bus, 22 kA IC bus bracing and 100% neutral termination, feed-through lugs provided on load centers with main breakers
- 320 A continuous duty meter socket available in ring type, K-4 bolt on, or ringless (lever bypass)
- All terminals accept copper or aluminum wire for added installation flexibility
- Utility meter socket compartment has barrier from main circuit breakers for utility power protection
- Factory installed flange for easy semi-flush or surface installation
- G90 galvanized steel construction for superior corrosion protection
- Durable polyester powder coat finish resists chipping and fading
- Underground feed only, series wired, 240 VAC 1-phase, and branch circuits accept combinations up to 200 A
- Fifth jaw optional - order model MS5MIL
- Line side 1/2 in stud termination provided, however, crimp-on/connector lug not provided by Midwest
- Bottom feed only, no hub provision
- 1 AWG to 300 kcmil stranded aluminum load connector
- Residential, Construction and Service Equipment Applications
- ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL Listed
