Lutron® NTR-15-GFST-BE Radio Frequency RF Switch, Screw Terminal Connection
Sku #78427615832
MFG #NTR-15-GFST-BE
Attributes
| Connection: | Screw Terminal |
| Operating Temperature: | 0 to 40 Degrees C |
| Dimensions: | 4.56 in (116 mm) x 2.75 in (70 mm) |
| Mounting: | Wall Box |
| Environmental Conditions: | 0 to 90% Humidity |
| Country of Origin: | CN |
- Continuous self-test functionality - disconnects power to receptacle if critical components are damaged and GFCI protection is lost, providing "continuous self-testing" that initiates within 2.5 seconds and is a continuous cycle every 30 seconds or less
- Manual Test - this design incorporates a full system test function
- The GFCI, when manually tested, induces a simulated ground fault leakage current to the printed circuit board, causing the mechanical system to react based on the action of the solenoid
- Reverse wire safety feature, if wired incorrectly there will be no power to the face or to downstream receptacles for added safety
- Clear visual indication of GFCI status LED indicating lights - - Green LED (power to the device) - Red LED (trip condition/ground fault condition) - Flashing Red LED (end of life)
- Permanently installed internal tamper-resistant shutter mechanism capable of resisting insertion of foreign elements into the device
- Internal back wiring clamp and guide pocket, quick and dependable termination
- UL, CSA, NOM, NEC, CEC, OSHA
