Sku #78393699718
MFG #GOB3-G23C N34
Attributes
| Type: | Long Indicator |
| Size: | 5-3/8 in L x 1-35/64 in W x 1-35/64 in H |
| Enclosure Type: | NEMA 3/4/4X/7/9 |
| Series: | SZ G |
| Voltage Rating: | 110 to 120 V AC |
| Temperature Rating: | -25 to 40 deg C/-50 to 40 deg C |
- CSA File No. LR11714, Class I, Div 1 and 2, Groups B,C,D4, Class I, Zones 1 and 2, Groups llB, llA, Class II, Div 1 and 2, Groups E,F,G Class Ill|UL File No. E12379
- Hazardous Location Applications
- Operators are all aluminum except for certain movable parts which are stainless steel, all other parts such as screws are either stainless steel or plated steel
- Threaded bodies are all 3/4-14 NPSM thread
- Control stations can be grouped into a single assembly thus reducing installation time and cost
- Junction boxes may be used to mount operators along with glass lens for viewing internally mounted meters
- Additional relays, timers, terminal blocks, or other equipment may also be internally mounted to provide a single centralized control unit
- -25 to 40 deg C according to UL/-50 to 40 deg C according to CSA temperature rating
