Sku #78393693340
MFG #XSX-2
Attributes
| Type: | 1-Gang Non-Factory Sealed |
| Voltage Rating: | 600 V AC |
| Motor Power: | 2 hp at 115 VAC, 2 hp at 200 to 230 VAC, 3 hp at 460 to 575 VAC |
| Series: | XSX |
| Frequency Rating: | 60 Hz |
| Number of Poles: | 2 |
- Operating shaft is stainless steel
- Multiple gang assemblies available in combination with pilot lights, pushbuttons and switches on request
- Ground flange joint between bolted cover and box provide required flame path
- Provisions for padlocking switch in either ON or OFF position is standard
- Provides manual starting and stopping of small AC or DC motors, motor running protection when overload heaters are used, ideally suited for across-the-line applications where a positive disconnect means is required
- CSA File No. LR11714|FM File No. 25219|CSA Certified|Class 1, Zones 1 and 2, Groups llB, llA|Class II, Divisions 1 and 2, Groups E, F, G|Class lll|UL File E53360/E12379|PROP65: This product can expose you to chemicals including Lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov
