Sku #78393621150
MFG #GESXAT-4
Attributes
| Type: | Type XAT |
| Size: | 1-1/4 in |
| Capacity: | 42 cu-in |
| Series: | GE Series |
| Cover Opening Size: | 3-9/16 in |
| Material: | Copper Free Aluminum |
- For use in hazardous areas to protect conductors in threaded rigid conduit, act as pull and splice boxes, interconnect lengths of conduit, change conduit direction and provide access to conductors for maintenance and future system changes
- CSA File No. LR11716, Class I, Div 1, 2, Group D, Class I, Zone 1, 2, Group IIA, Class II, Div 1, 2, Group E, F, G, Class III, Div 1, 2|UL 886|UL File No. E10514|CSA C22.2 No. 30|Class II, Division 1, 2, Group E, F, G|Federal Specification W-C-586D|Military Specification F-28675
- Water shedding cover suitable for wet locations when mounted in upright position
- External cover threads on body protecting conductors from damage during pulling
- Taper threaded hubs to provide ground continuity
- Smooth integral hub bushing to protect conductor insulation when pulling
- Internally threaded cover openings for additional wiring room
- Covers furnished with boxes
- Weather-resistant finish
- Green ground screw standard
