Sku #78393621040
MFG #GECEAT-2
Attributes
| Type: | Type EAT Round Shape |
| Size: | 3/4 in |
| Capacity: | 19 cu-in |
| Series: | GEC |
| Cover Opening Size: | 2-11/16 in |
| Suitable For Use With: | Hazardous Area Conduit System |
- Water shedding cover suitable for wet locations when mounted in upright position
- External cover threads on body protecting conductors from damage during pulling
- Taper threaded hubs to provide ground continuity
- Smooth integral hub bushing to protect conductor insulation when pulling
- Internally threaded cover openings for additional wiring room
- Covers furnished with boxes
- Weather-resistant finish
- Green ground screw standard
- Used in hazardous areas to protect conductors in threaded rigid conduit, act as pull and splice boxes, interconnect lengths of conduit, change conduit direction and provide access to conductors for maintenance and future system changes
- UL 1203|UL File No. E10514|CSA C22.2 No. 30|CSA File No. LR11716|Class I, Zone 1, 2, Group IIB, IIA|Military Specification F-28675|UL 886|Federal Specification W-C-586D|Military Specification F-28675 Class I, Div 1, 2, Groups B, C, D/Class I, Zones 1, 2, Groups IIB + H2/Class II, Div 1, 2, Groups E, F, G/Class III
