Sku #78393613303
MFG #HKH1ANDAM41E
Attributes
| Type: | Hazardous Location |
| Voltage Rating: | 690 V AC |
| Number of Operators: | 1 |
| Series: | HKH |
| Amperage Rating: | 20 A |
| Contact Configuration: | 1NO-1NC |
- Size 1 Control Stations available as 1a, 1b, and 1c as standard catalog number offerings for 1, 2 and 3 device openings and will accept 2-M20 entries in either end
- Operating Temperature of -50C to +60C
- Explosion Protected contact blocks 690 VAC N.O. and N.C. capable of 20 Afor Switching Duty and HP Ratings up to 1HP
- 12-254V AC/DC for IEC applications
- Contacts and Pilot lights can be mounted inside enclosure on Din Rail or in cover to the actuator
- Accessories available for Lockout/Tag Out functions made in 316 stainless steel
- For hazardous and corrosive environments due to the presence of flammable gases or vapors, combustible dusts or ignitable fiber or flyings, Installations at petroleum refineries, chemical and petrochemical plants and other processing or storage facilities where similar hazards exist, Use in conjunction with motor starters or contactors for remote control of motors
- Class I, Division 2, Groups A, B, C, D Class II, Division 1, Groups E, F, G (Canada Only) Class II, Division 2, Groups E, F, G Class III, Divisions 1 and 2 Zones 1 and 2 Zones 21 and 22
