Sku #78393607669
MFG #UGP-15232QW
Attributes
| Type: | 1-Phase Interchangeable Blade Style |
| Voltage Rating: | 250 V AC |
| Frequency Rating: | 60 Hz |
| Series: | ACCEPTOR® UGP |
| Amperage Rating: | 15 A |
| Number of Poles: | 2 |
- Class I, Div 1 and 2, Group C, D, Class I, Zone 1 and 2, Group IIB, IIA, Class II, Div 1 and 2, Group F, G, Class III, Div 1 and 2|cCSAus File No. LR14667|UL File No. E91049/E53660
- Petroleum Refineries, Chemical Plants, Wet/Damp Areas, Corrosive Environments, Petroleum Plants, Grain Elevators, Flour and Feed Mills and Indoor or Outdoor Locations Applications
- Factory sealed chamber in UGR receptacle contains switchs arcing components
- Spring loaded receptacle cover closes when plug is removed
- Copper-free aluminum (less than 4/10 of 1%) alloy resists corrosion
- Electrostatically applied and baked powder epoxy/polyester finish
- ACCEPTOR plugs conform to NEMA configurations, while it's turn to engage feature locks in plug and can be used to prevent accidental disengagement of critical equipment
- Plugs for use with type S/SO/ST/STO heavy duty cord
