Sku #78393604785
MFG #LL97CG
Attributes
| Type: | Type LL |
| Number of Hubs: | 2 |
| Form: | Form 7 |
| Hub Size: | 3-1/2 in |
| Capacity: | 238 cu-in |
| Enclosure: | NEMA 3 |
- UL File No. E3397|CSA File No. LR11852|Federal Specification W-C-586D/A-A 50563|NEC 501.10(b) Class I Div 2, 502.10, 503.10
- To provide access to conductors for pulling, splicing and maintenance, threaded for rigid and IMC conduit
- Intermateability UL listed and CSA certified interchangeability with competitive products
- Enhanced sealing capabilities neoprene sealing gaskets provide a NEMA 3 seal
- For wet locations when used with gasketed covers
- Innovative spring clip design for installation ease and repeat usage
- Smooth integral wire bushings protects cable from damage when wires are pulled through opening
- For use with threaded rigid conduit steel or aluminum
- Flat back design for greater wiring capacity and mounting stability
- Tri-coat finish of electro-zinc, chromate sealant and electrostatically applied powder coating
- High quality sealing hardware 316 stainless steel cover screws and washers with neoprene gaskets
