ILSCO® PBTD-4-750-M-F Mechanical Insulated Cable Taps

Documents

ILSCO® NIMBUS®4FLEX PBTD-4-750-M-F 4-Port Type PBTF Single Sided Entry Mountable Insulated Multi-Tap Connector, 4/0 AWG to 750 kcmil Aluminum/Copper Conductor

Sku #78366972450

MFG #PBTD-4-750-M-F

Attributes

Type:	4-Port Type PBTF Single Sided Entry Mountable
Conductor Size:	4/0 AWG to 750 kcmil
Specifications:	535 A, 1/2 in Hex

Conductor Type:	Aluminum/Copper
Voltage Rating:	600 V AC
Temperature Rating:	-45 to 90 deg C

Dual rated for copper and aluminum conductor
Cold temperature rated to -45 deg C
High dielectric strength plastisol is chemical resistant
Black cover is UV rated
Removable port and screw plugs
Pre-filled with De-ox®

UL 486A/B/453G File No. E6207|CSA File No. LR29601|NEC 310-316|PROP65: Cancer and Reproductive Harm - www.P65warnings.ca.gov

Documents

Specification Sheet

ILSCO®ILSCO® NIMBUS®4FLEX PBTD-4-750-M-F 4-Port Type PBTF Single Sided Entry Mountable Insulated Multi-Tap Connector, 4/0 AWG to 750 kcmil Aluminum/Copper Conductor

SKU #78366972450

MFG #PBTD-4-750-M-F
