ILSCO® SureCrimp® CSWD-700-12-134 CSWD 2-Hole Lug Compression Connector With Sight Hole, 700 kcmil Copper Conductor, Die Code: I-99, 1/2 in Stud
Sku #78366964885
MFG #CSWD-700-12-134
Attributes
| Type: | 2-Hole |
| Conductor Type: | Copper |
| Die Code: | I-99 |
| Series: | CSWD |
| Conductor Size: | 700 kcmil |
| Voltage Rating: | 600 V AC |
- Electro-tin plated
- Manufactured from high strength seamless copper tubing
- Color coded
- Suitable for use in circuits rated 35 kV or less, Proper high voltage spacing and insulation techniques must be used
- UL listed and CSA certified with ILSCO® and major competitors compression tools
- UL 467 listed 8 AWG to 500 kcmil, 8 to 2 AWG solid conductor size
- Offers maximum conductivity and excellent crimping characteristics
- Provides low contact resistance
- For easy conductor insertion
- Identifies the proper compression die
- Application versatility
- Reduces inventory requirements
- For grounding and bonding applications
- Alternate conductor size of 500 G, H, I, K, M flexible 535.3 DLO
- 350 to 700 kcmil expanded conductor size
- NEBS Level 3|UL 453G/486A-B/E6207|CSA LR-29601
- For terminating connector
