ILSCO® ClearChoice® D-2740 Type CO-PP Compact Box Mechanical Lug With Pressure Plate, 4/0 to 2 AWG Copper Conductor, 1 Bolt Hole, Copper
Sku #78366902820
MFG #D-2740
Attributes
| Type: | Type CO-PP Compact Box |
| Conductor Size: | 4/0 to 2 AWG |
| Voltage Rating: | 2000 V AC |
| Conductor Type: | Copper |
| Number of Bolt Holes: | 1 |
| Specifications: | 1/4-20 Boss Mounting Hole Tapped |
- CSA File No. LR-29601|UL 486A-B/UL File No. E6207|UR Listed
- For terminating connector
- Re-usable
- Suitable for use in circuits rated 35 kV or less, proper high voltage spacing and insulation techniques must be used
- Range taking for reduced inventories and flexibility and provides efficient use and flexibility in the field
- Manufactured from electrolytic seamless copper tubing provides maximum conductivity and strength
- Electro-tin plated provides low contact resistance
- Ensures reliability for copper conductor
- Compact design saves space and reduces installation time
- Application versatility
- Bossed mounting holes act as an anti-rotation device and prevents connector from turning
- Pressure plate prevents screw damage to the conductor
- For copper conductor only
- 0.2825 to 0.2875 in round bottom outside boss
- 9/16-24 steel hex head set screw in top
