Hubbell Wiring Device-Kellems HBL18201CN HBL® 2-Position Extra Heavy Duty Standard Toggle Switch, 347 V AC, 15 A, 5540 W Power Rating, 2-Position Contact
Sku #78358592468
MFG #HBL18201CN
Attributes
| Type: | 2-Position Extra Heavy Duty Standard |
| Voltage Rating: | 347 V AC |
| Power Rating: | 5540 W |
| Series: | HBL® |
| Amperage Rating: | 15 A |
| Contact Configuration: | 2-Position |
- Minimum 4.8 times rated current for 100 cycles overload
- Abuse resistant nylon toggle
- Large brass binding head screws with deep slots
- Thermoset top and base
- Silver alloy contacts
- Positive snap action
- Strip gauge for accurate wiring
- 30 deg maximum at rated current temperature rise
- 14 to 10 AWG solid and stranded copper wire size
- Withstands 1500 VAC minimum dielectric voltage for 1 min
- Thread cleaning captive mounting screw
- Brass (green) ground screw
- 1/2 hp at 120 VAC, 2 hp at 208/240/277 VAC
- General Purpose Industrial Applications
- UL94 V-2 Flammability Rating|Federal Specification WS896|UL 20|CSA Certified|NEMA WD1
