Hubbell Wiring Device-Kellems Twist-Lock® L1520P 3-Phase Grounding Standard Sized Cord Mount Locking Male Plug, 250 V AC, 20 A, 3 Poles, 4 Wires, Black
Sku #78358583589
MFG #L1520P
Attributes
| Type: | 3-Phase Grounding Standard Sized Cord Mount |
| Amperage Rating: | 20 A |
| Number of Wires: | 4 |
| Voltage Rating: | 250 V AC |
| Number of Poles: | 3 |
| NEMA Rating: | L15-20P |
- Visible NEMA ratings
- Captive assembly screws
- Supertough® nylon body
- Impact modified nylon blade/contact holder
- Brass contacts/blade
- Withstands 3500 VAC per UL 498 dielectric voltage
- 600 VAC or 250 VDC maximum working voltage
- Maximum 30 deg C temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per UL 498
- Minimum 4.8 times rated current for 100 cycles overload
- Terminals identified in accordance with UL 498 (brass, white, green)
- 18 to 8 AWG flexible cord
- Ratings and NEMA identification are permanently marked on device
- Indoor dry unless protected by additional means
- 14 to 10 AWG wire
- For power connection applications
- CSA Certified|RoHS Compliant|UL Listed
