Hubbell Wiring Device-Kellems SNAP2162WSC Decorator Duplex Extra Heavy Duty Split Circuit Straight Blade Receptacle, 250/220 to 240 V AC, 60 A, 2 Poles, 3 Wires, Blue
Sku #78358524976
MFG #SNAP2162WSC
Attributes
| Type: | 1-Phase Decorator Duplex Extra Heavy Duty Split Circuit |
| Amperage Rating: | 60 A |
| Number of Poles: | 2 |
| Voltage Rating: | 250/220 to 240 V AC |
| Horsepower: | 1 hp |
| Number of Wires: | 3 |
- Aesthetic Style Line® decorator design
- Audible SNAP, indicates solid connection
- Reduces installation time
- Fully insulated design
- Modular wiring system eliminates screw terminals
- Speeds installation and trim out
- Clear polycarbonate terminal housing to inspect contacts
- Abuse resistant nylon for extra heavy use applications
- Stainless steel auto ground
- Education, Hospitality, Commercial Construction, Pre-Fab Assembly and OEM Applications
- CSA C22.2 No. 42 File 285|Federal Specification WC596|UL Listed to UL498 File No. E2186, BAA Compliant|UL94 V-2 Flammability Rating|NEMA WD6
