Hubbell Wiring Device-Kellems SpikeShield® HBL® IG8310R 1-Phase Extra Heavy Duty Isolated Ground Single Standard Screw Mount Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Red
Sku #78358514889
MFG #IG8310R
Attributes
| Type: | 1-Phase Extra Heavy Duty Isolated Ground Single Standard Screw Mount |
| Amperage Rating: | 20 A |
| Number of Poles: | 2 |
| Voltage Rating: | 125 V AC |
| Horsepower: | 1 hp |
| Number of Wires: | 3 |
- C22.2 No. 42|Federal Specification W-C-596|NEMA WD1/WD5|UL 498 File No. E2186
- Dimensionally stable, reinforced thermoplastic polyester provides impact strength in addition to heat and flame resistance
- Impact resistant nylon smooth face
- Wraparound, locked on brass mounting strap provides additional support strength for receptacle assembly
- Automatic self-grounding clip assures ground continuity between mounting strap and metal wall box
- IG triangle on the face of the receptacle clearly indicates isolated ground device
- Amperage and voltage clearly indicated
- Back and side wiring capability provides easy installation with stranded or solid wire
- Green grounding screw connected directly to the grounding contacts
- Insulation barrier construction is first patented by Hubbell® isolates ground contacts from the mounting strap
- Square head, 10-thread bronze center rivet won't rotate, reduces stripping and resists corrosion
- Patented bypass contact design
