SolaHD ES5H75S Ventilated Distribution Transformer With WS-17 Optional Weather Shield, 240/480 V AC Primary, 120/240 VAC Secondary, 75 kVA, 60 Hz, 1 Phase
Sku #78347200024
MFG #ES5H75S
Attributes
| Type: | Ventilated |
| Secondary Voltage: | 120/240 V AC |
| Frequency Rating: | 60 Hz |
| Primary Voltage: | 240/480 V AC |
| Power Rating: | 75 kVA |
| Phase: | 1 |
- Terminal board connections and spacious wiring compartment
- Panel enclosure design reduces labor time, wiring diagram on inside front cover
- High efficiency for low cost operation
- Copper wound designs
- Low temperature designs
- Electrostatic shield for quality power
- Energy efficient dry-type
- Fast delivery
- Compliant with NEMA TP-1 standards, 1 and 3-phase models
- 302 deg F temperature rise under full load
- ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL 1561 File No. E25872
- For any situation where the available voltage must be changed to accommodate the voltage required by the specific electrical circuit or connected equipment and outdoor applications
