O-Z/Gedney NEPL5CL Dust-Ignitionproof Explosionproof Standard Long Barrel Pilot Light, 120/600 V AC, Bolt Mount
Sku #78312698103
MFG #NEPL5CL
Attributes
| Type: | Dust-Ignitionproof Explosionproof Standard Long Barrel |
| Lens Color: | Clear |
| Size: | 1-1/2 in Dia |
| Voltage Rating: | 120/600 V AC |
| Lens Material: | Glass |
| Enclosure Type: | NEMA 4/7B/7C/7D/9E/9F/9G |
- Precision machined flame path between body and cover
- O-ring gasket ensures watertight integrity
- Bolt-on stainless steel slotted mounting feet
- External flange maximizes internal space
- Flexible hinge mounting on either side
- Wall thickness suitable for minimum of five full threads
- Factory assembled and wired to specifications
- Operators are spaced on 2-1/2 in centers
- Provision for mounting pan
- Ground lug package and installation instructions for termination of ground wires enclosed
- For hazardous locations
- NEC/CEC Class I, Division 1, 2, Group B, C, D, Class I, Zone 1, 2, Group IIA, IIB, Class II, Division 1, 2, Group E, F, G, Class III|UL 886|CSA C22.2
