O-Z/Gedney Spec 5 T-250G Type T ™ Conduit Body, 2-1/2 in Hub, Form 35 Form, 146 cu-in Capacity, Malleable Iron, Aluminum Enamel/Hot Dipped Galvanized
Sku #78312651820
MFG #T-250G
Attributes
| Type: | Type T |
| Number of Hubs: | 3 |
| Form: | Form 35 |
| Hub Size: | 2-1/2 in |
| Capacity: | 146 cu-in |
| Connection Type: | Tapered NPT |
- For use to serve as pulling fittings, make bends in conduit system, provide openings for splicing, connect and change direction of conduit runs, allow connections for branch runs, IMC and rigid conduit
- ARRA Compliant|UL 514A File No. E18095|CSA C22.2 No. 18 009795|Federal Specification A-A-50563|NEC/CEC Hazardous Locations Class 1 Division 2 Per NEC Section 501-4(B)|NEMA:FB-1, FB-2.10
- Smooth, rounded integral bushings in hubs protect conductor insulation
- Accurately tapped, tapered threads for tight, rigid joints and excellent ground continuity
- Form 35™ malleable iron Unilets™ are high tensile strength and ductility
- High corrosion resistance, high impact and shock resistance
- Sizes with flat back design ideal where fitting is mounted flat against surface
- 1/2 to 3 in blank covers are domed for extra wiring space
- Raintight when an Appleton™ cover and gasket are installed
