nVent ERICO CADWELD® NTK18Y5Y6 Type NT Weld Metal Mold, 95 sq-mm/120 sq-mm Concentric Conductor, 3/4 in Rod, Cable to Cable Connection, Copper/Graphite
Sku #78285685714
MFG #NTK18Y5Y6
Attributes
| Type: | Type NT |
| Rod Size: | 3/4 in |
| Mold Price Key: | K |
| Conductor Size: | 95 sq-mm/120 sq-mm Concentric |
| Connection Type: | Cable to Cable |
| Specifications: | 0.505 x 0.567 in OD Conductor |
- Computer Room, Tunnel or Other Low Ventilation Area Applications
- Forms a permanent, low resistance connection
- Provides a molecular bond
- nVent ERICO CADWELD® exothermic connections are rated with the same current capacity as the conductor
- Portable installation equipment with no external source of power required
- Connections can be visually inspected
- To Ground Rod/Other Rounds
- ANSI/UL 467 UL File No. KDER.E220029|cULus File No. KDER7.E220029|CSA C22.2 File No. 41
- Frame
