nVent ERICO TDS11002SR560 Transient Discriminating Surge Diverter, 480 to 560 V AC, 0 to 100 Hz, 200 kA SCCR
Sku #78285658538
MFG #TDS11002SR560
Attributes
| Type: | Transient Discriminating |
| Electrical Ratings: | 480 to 560 V AC |
| Short Circuit Current Rating: | 200 kA |
| Series: | TDS1100 |
| Frequency Rating: | 0 to 100 Hz |
| Nominal Discharge Current: | 40 kA |
- TD Technology with thermal disconnect protection
- Compact design fits into DIN distribution panel boards and motor control centers
- Indication flags and voltage-free contacts provide remote status monitoring
- Separate plug and base design facilitates replacement of a failed surge module
- 100kA 8/20micros maximum surge rating provides protection suitable for sub-distribution panels and a long operational life
- RoHS Compliant|ANSI/IEEE C62.41.2-2002 Cat A/Cat B/Cat C|ANSI/IEEE C62.41.2-2002 Scenario II/Exposure 3|IEC 61643-1 Class I/Class II|CE Certified|cULus Recognized|UL 94 V-0 Flammability Rating
