BUCHANAN B-TAP® BTC500-14 Insulation-Piercing Piercing Insulated Tap Connector, 4/0 AWG to 500 kcmil Main, 1/0 AWG to 350 kcmil Tap Solid/Stranded Conductor
Sku #78178945451
MFG #BTC500-14
Attributes
| Type: | Insulation-Piercing |
| Conductor Size: | 4/0 AWG to 500 kcmil Main, 1/0 AWG to 350 kcmil Tap |
| Specifications: | 1-Bolt, 2.2 in-lb Torque, 1/2 in Socket |
| Conductor Type: | Solid/Stranded |
| Voltage Rating: | 600 V AC |
| Temperature Rating: | 90 deg C |
- Breakaway torque nut snaps off when UL torque requirements are met
- Second nut remains for easy connector removal
- Self-insulated housing eliminates the need for tape
- Safely installs on energized systems
- Grease-filled end cap seals end of conductor for superior weather protection
- Grease-filled boots protect copper teeth from corrosion and prevent arcing
- Hardened copper teeth pierce insulation and bite into conductors
- CSA Certified|RoHS Compliant|UL Listed
