Appleton® KRG2S Guard, For Use With Short Type V Refractor, Stainless Steel
Sku #78138160372
MFG #KRG2S
Attributes
| Suitable For Use With: | Short Type V Refractor |
| Material: | Stainless Steel |
- Typical applications include pulp and paper mills, processing plants, chemical plants, oil refineries, foundries, manufacturing plants, storage areas, waste and sewage treatment, parking garages, and other areas where dust, water, dirt and rough usage are a problem
- Design is suited for low mounting heights, from 7 ft., up to 30 ft
- Choice of optics for optimal light distribution in a variety of applications: Type I, Type III, Type V or Type V Wide
- Modular design provides thousands of combinations for maximum versatility: four different globe options for the Standard version (three different globe options for the Emergency version) and seven standard mounting hoods
- Retrofit adapters for Crouse-Hinds™ Killark, and Mercmaster™ II hoods available
- Hinge has high lip for added safety during installation and servicing. Hinge and bolt construction assures 360 deg compression at all points on fixture housing gasket for positive sealing. Swing away design of captive bolt and nut simplifies installation
- Standard 6 kV surge protection with an option to upgrade to 10kV, heavy duty, high temperature silicone gaskets and a rugged housing with superior thermal design translates to long luminaire life
- Standard NPT threads with M20 option on Standard version
- Field replaceable globes and LED driver
- Awide range of industrial, chemical processing and other areas where flammable gases and vapors or combustible dusts may be present. Marine and wet locations. Suitability includes use where there may be simultaneous exposure to flammable gases and vapors or combustible dusts. Power plants. Processing plants. Chemical plants. Oil Refineries. Waste and sewage treatment. Hydrogen and Biofuels plants. LNG (Liquid Natural Gas) plants. Other areas where dust, water, dirt and rough usage are a problem
- UL Standard UL 844, UL 1598, UL 1598A, UL 50E, UL 8750, UL 60079-0, UL 60079-7, UL 60079-31|CSA Standard C22.2 No. 0 - 10, C22.2 No. 94.2 - 15, C22.2 No. 137 -M1981, C22.2 No. 250.0 - 08, C22.2 No. 250.13 -14, C22.2 No. 60529,C22.2 No. 60079-015, C22.2 No. 60079-716, C22.2 No. 60079-3115, CSA E60598-116|cCSAus 164460, Certificate Number 70112879
