Appleton® Mercmaster™ III 250 KPBR100L-MT KP Series HPF Ballast Body, High Pressure Sodium Lamp, 100 W Lamp, 120/208/240/277 V AC, 16.96 in L
Sku #78138154903
MFG #KPBR100L-MT
Attributes
| Type: | HPF |
| Lamp Type: | High Pressure Sodium |
| Wattage: | 130 W |
| Series: | KP Series |
| Lamp Wattage: | 100 W |
| Voltage Rating: | 120/208/240/277 V AC |
- The Mercmaster™ III series provides a wide selection of high quality enclosed and gasketed luminaires for use in demanding industrial environments and hazardous locations
- Epoxy powder coat finish electrostatically applied for complete uniform corrosion protection
- Modular design allows scores of fixture component combinations to meet installation and lighting needs
- Hinge has high lip for added safety during installation and servicing
- Hinge and bolt construction ensures 360 DEG compression at all points on ballast housing gasket for positive sealing
- Swing away design of captive bolt and nut simplifies servicing
- Body gaskets and globe gaskets are high temperature silicone rubber
- Capacitors are non-PCB type, thermally isolated from ballast
- Mogul base porcelain socket with nickel plated contacts has 200 deg C welded leads, prewired to the ballast to ensure trouble free operation in high ambient temperatures
- All Mercmaster™ III mounting hoods have provision for easy field installation
- Pulp and Paper Mills, Processing Plants, Chemical Plants, Oil Refineries, Foundries, Manufacturing Plants, Storage Areas and Marine Applications
- CSA 025428|CSA C22.2 File No.9, C22.2 File No.137, CAN|CSA E60079-0, E60079-15|UL Standard ANSI|UL 844, 1598, 60079-0, 60079-15|UL Listed for Class I, Div 2, Groups A, B, C, D, Class I, Zone 2, AEx nA nR IIC (Z2), Class I, Zone 2, AEx nR IIC (ZB), Class II, Div 1 and 2, Groups E, F, G, Class III
