Appleton® U-Line™ ECS72023 2-Gang Dust-Ignitionproof Pin and Sleeve Receptacle Assembly, 125 V AC, 15/20 A, 3 Poles, 2 Wires, Gray
Sku #78138130642
MFG #ECS72023
Attributes
| Type: | 2-Gang Dust-Ignitionproof |
| Voltage Rating: | 125 V AC |
| Horsepower: | 1 hp |
| Series: | ECS |
| Amperage Rating: | 15/20 A |
| Number of Poles: | 3 |
- Highly corrosive atmospheres and Wet Locations
- Factory sealed, external seals not required in most areas, arcing is safely confined to receptacle interior
- Unique blade type, brass contacts exert constant pressure along entire contact surface and provide superior electrical contact
- Energized receptacle contacts deeply recessed to reduce danger of accidental touching
- Insulators provide superior dielectric and mechanical strength and lowest arc tracking
- ECP plug fits any standard non-explosionproof receptacle (NEMA 5-20R or 6-20R) as well as U-Line® explosionproof receptacles
- Intermateable with competitor's plugs of like configurations
- (2) Single Receptacle Cover
- Class I, Division 1 and 2, Groups B, C, D Class I Zone 1 and 2, IIB + H2 T6, Class II, Division 1 and 2 Group G, Class III|CSA C22.2
