Appleton® U83W4PRA5A9 Unicode™ 2 Bottom Control Station, 1NO-1NC Contact, 2 Operators
Sku #78138126258
MFG #U83W4PRA5A9
Attributes
| Type: | Bottom |
| Number of Operators: | 2 |
| Contact Rating: | 10 A at 600 V AC |
| Series: | Unicode™ 2 |
| Contact Configuration: | 1NO-1NC |
| Actuator: | Push Button |
- For the control of equipment at power, chemical and petrochemical plants, petroleum refineries, re-verse osmosis plants, pulp and paper processing plants and various industrial applications and hazardous location
- Employs Ex de method of protection which eliminates the need for external seals
- Operators include pushbuttons, illuminated pushbuttons, selector switches, control and load break switches and LED pilot lights
- Pilot light employs high intensity single LED with lifetime of 100000 hr that can be used at 12 VAC to 254 VAC 50/60 Hz and 12 VDC to 60 VDC
- Up to 3 contact blocks per actuator can be used
- Enclosures are rated for IP66 with firmly secured gasket
- Operators and contact blocks are spaced for easy wiring
- Choice of DIN rail mounted high performance contact block suitable for low intensity (less than 5 mA)
- TS35 rail mounted components are held securely in place during operation and easily removed for service
- Brass inserts are provided for TS35 DIN rails or mounting plates to be installed inside the enclosure
- (1) 12 to 254 VAC/12 to 60 VDC red LED pilot light
- Constructional feature explosionproof
- Increased safety
- With 1 NO momentary contact pushbuttons, momentary contacts (3 maximum)
- (1) White Self-Adhesive Laminated Plastic Nameplate, (1) Brass Earth Continuity Plate, (1) Blanking Plug and (1) Cable Gland
- 1 Year Limited
- ATEX LCIE 02/6047|ATEX/IECE Zone 1 and 2-21 and 22, II 2 GD, Ex de IIC/Ex demb IIC/Ex tD A21|IK10|cULus Listed|CE 50221|EN/IEC 60529|EURASEC RU C-FR 05.B.00911
