Sku #78108707356
MFG #197954
Attributes
| Type: | Electronic |
| Wattage: | 227 to 343 W |
| Amperage Rating: | 0.82 to 1.8 A |
| Lamp Wattage: | 210/315 W |
| Voltage Rating: | 120 to 277 V AC |
| Frequency Rating: | 50/60 Hz |
- IntelliVolt® operates on either 120 or 277 VAC or any voltage in between 50/60 Hz
- Smaller and lighter weight than magnetic HID F-can ballasts
- Compact footprints provides greater design flexibility
- Reduced input watts compared to magnetic systems, energy savings, lower cost of ownership
- Low frequency lamp operation prevents acoustic resoce in the lamp arc tube
- Square wave output waveform helps maximize lamp life
- Lamp EOL detection shuts down system at lamp end of life, enhanced safeguard
- Thermally protected, internally fused and output short circuit protected
- Lamp wattage will change less than 0.5% with a +/-10% change in-line voltage
- Metallic enclosure provides enhanced capability for high ambient temperatures by transferring heat away from sensitive internal components
- 0 to 10 VDC dimming
- Leads (side exit) with mounting feet
- CSA certificate;UL certificate;NOM certificate;RoHS Compliant
