Square D™ MJL36800E10SK PowerPact M Series Circuit Breaker, 600 VAC, 300-800 A, 25 to 100 kA interrupt, 3 poles, Magnetic trip
Sku #60648628503
MFG #MJL36800E10SK
Attributes
| Type: | Circuit Breaker |
| Voltage Rating: | 600 V AC |
| Frequency Rating: | 50/60 Hz |
| Series: | PowerPact M Series |
| Amperage Rating: | 300-800 A |
| Interrupt Rating: | 25 to 100 kA |
- Available in 2-3 pole design
- Available from 300-800 A at up to 600 Vac
- Interrupting ratings (AIR) include G-35 kA, J-65 kA at 480Vac
- Available in standard (80%) rating only
- Common accessories across the range of PowerPact Molded Case Circuit Breakers allow users to make late specification changes
- A wide range of field-installable accessories allows customers to reduce inventory without sacrificing flexibility
- IEC Style Rotary Operating Handles
- NEMA 9421 Door Mounted Rotary Operating Mechanism
- NEMA 9422 Flange Mounted Operating Mechanism in two styles - bracket mounted or cable operated
- Available in Unit-mount and I-line constructions
- UL 489 Listed, CSA, NMX, IEC certified for world wide applications
- 300-800 A current sensor rating range
- M-frame circuit breaker type
- 80 % continuous current rating
- 1600 to 8000 A magnetic tripping current
- AL800M23K terminal identifier
- With pvc free
