Schneider Electric Modicon™ Quantum™ Square D™ 140ACO13000 Analog Output Module, 8 Outputs
Sku #59586114801
MFG #140ACO13000
Attributes
| Number of Outputs: | 8 |
| Amperage Rating: | 0 to 20 mA |
| Temperature Rating: | 0 to 60 deg C |
| Voltage Rating: | 6 to 30 V DC |
| Power Rating: | 5 W |
- Modicon Quantum Automation Platform Applications
- CE Certified|CSA C22.2 File No. 142|cUL Listed|FM Class 1 Division 2|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov|RoHS Compliant|UL 508
- Eight-output words addressing requirement
- 6 to 30 VDC loop voltage
- 6 to 30 V 25 mA voltage drop
- +/-0.2% of full scale at 25 deg C absolute accuracy error
- 0.004% of full scale/deg C typical, 0.007% of full scale/deg C maximum accuracy drift according to temperature
- 1780 V for 1 min AC isolation between channel and bus
- 5 ms update time
- 1.6 ms to 5% of the final value, 3.2 ms to +/-0.1% of the final value setting time
- Open circuit 4 to 20 mA fault type
- 550 mA bus current requirement
- 5 W power dissipation
- 6 to 30 V external power requirement
- Standard module format
- 10 V/m 80 to 2000 MHz conforming to IEC 801-3-resistance to electromagnetic field
- -40 to 85 deg C ambient air temperature for storage
- 95% without condensation relative humidity
- <=5000 m operating altitude
- (1) LED green bus communication is present (active), (1) LED red external fault, 8-LED green channel is turned on, 8-LED red channel fault
- 0 to 20 mA, 0 to 25 mA or 4 to 20 mA
