Schneider Electric Modicon® Quantum™ 140ARI03010 Analog I/O Module, 8 Inputs, 13 bit Resolution
Sku #59586113316
MFG #140ARI03010
Attributes
| Number of Inputs: | 8 |
| Power Rating: | 1 W |
| Resolution: | 13 bit |
| Temperature Rating: | 0 to 60 deg C |
- Differential input
- 9 input words addressing requirement
- >/=10 MOhm input impedance
- 0.1 deg C absolute accuracy error
- +/-0.01% full scale, +/-0.5 deg C linearity error
- +/-0.5 deg C at 25 deg C, +/-0.9 deg C at 0 to 60 deg C accuracy drift according to temperature
- 2500 VDC for 60 s, 1780 VAC 47 to 63 Hz for 60 s isolation between channel and bus
- 300 VRMs AC isolation between channel
- 1200 ms 3-wire, 640 ms 2-wire or 4-wire update time
- Broken wire, over tacking scale fault type
- 200 mA bus current requirement
- 1 W power dissipation
- Standard module format
- 4 kV contacts conforming to IEC 801-2, 8 kV on air conforming to IEC 801-2 resistance to electrostatic discharge
- 10 V/m 80 to 1000 MHz conforming to IEC 801-3 resistance to electromagnetic fields
- -40 to 85 deg C ambient air temperature for storage
- 95% without condensation relative humidity
- 1-LED green bus communication is present (active), 1-LED red external fault, 8-LED green channel is turned on, 8-LED red channel fault
- Thermal probe NI or PT 100, 200, 500, 1000
- RoHS Compliant|CE Marked|FM Class 1 Div 2|CSA C22.2 No. 142|cUL Listed|UL 508|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65Warnings.ca.gov
- Modicon® Quantum™ Automation Platform Applications
