Schneider Electric Modicon® Quantum™ 140DAO84000 Isolated Discrete Output Module, 16 Inputs, 16 Outputs
Sku #59586112697
MFG #140DAO84000
Attributes
| Type: | Isolated |
| Number of Outputs: | 16 |
| Temperature Rating: | 0 to 60 deg C |
| Number of Inputs: | 16 |
| Voltage Rating: | 24 to 230 V AC |
| Dimensions: | 11.41 in H x 4.01 in W |
- Modicon® Quantum™ Automation Platform Applications
- 16 groups of 1-channel
- 1-output word addressing requirement
- Isolated discrete output
- 47 to 63 Hz network frequency
- 1.5 V voltage drop
- 300 VRMs for 10 s AC/400 VRMs 1 cycle AC absolute maximum output
- <=10 A during 3 cycles per point, <=20 A during 2 cycles per point, <=30 A during 1 cycle per point surge current
- <=0.5 ms at state 0 to state 1, <=0.5 ms at state 1 to state 0 response time
- Internal by RC filter protection
- 1.85 +(1.1 V x total module load current) power dissipation
- 5 A associated fuse rating
- 350 mA bus current
- 95% without condensation relative humidity
- <=5000 m operating altitude
- Standard module format
- -40 to 185 deg F storage temperature
- (1) LED green bus communication is present (active), (1) LED red external fault detected (F), 16 LEDs green input status
- RoHS Compliant|CE Certified|CSA C22.2 File No. 142|cUL Listed|FM Class 1 Division 2|UL 508|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
