Schneider Electric Modicon™ Quantum™ Square D™ 140DDO84300 Discrete Output Module, 16 Inputs, 16 Outputs
Sku #59586100011
MFG #140DDO84300
Attributes
| Number of Inputs: | 16 |
| Voltage Rating: | 10 to 60 V DC |
| Dimensions: | 4.01 in W x 11.41 in H |
| Number of Outputs: | 16 |
| Temperature Rating: | 0 to 60 deg C |
- ABS Approved|Bureau Veritas Approved|C-Tick Approved|CE Certified|CSA C22.2 File No. 142|cUL Listed|FM CLASS 1 DIVISION 2|FM Class 1 Division 2|GOST Certified|IEC 801-2-8/801-2|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov|RINA Approved|RMRS|RMRS Approved|RoHS Compliant|UL 508
- Two-groups of eight-channel
- Negative logic (sink) discrete output
- One-output word addressing requirement
- 72 VAC permanent absolute maximum output
- <=1 V at 2 A voltage drop
- 12 A per module/6 A per group maximum load current
- <=7.5 A for 50 s surge current
- <=1 ms at state 0 to state 1, <=1 ms at state 1 to state 0 response time
- <=1 mA at 60 VAC leakage current
- 2 A each point/8 A per group associated fuse rating
- 2500 VRMs DC for 1 min isolation between channel and bus
- 700 VRMs DC for 1 min isolation between group
- Internal output protection by 8 A fuse per group protection
- 1 W +(1 V x total module load current) power dissipation
- 160 mA bus current
- 4 kV contact conforming to IEC 801-2, 8 kV on air conforming to IEC 801-2-resistance to electrostatic discharge
- 10 V/m 80 to 2000 MHz conforming to IEC 801-3-resistance to electromagnetic field
- 95% relative humidity without condensation
- <=5000 m operating altitude
- Standard module format
- Modicon® Quantum™ Automation Platform Applications
