Schneider Electric Modicon® Quantum™ 140DAI75300 VAC Discrete Input Module, 32 Inputs, 32 Outputs, 230 V AC Signal Range
Sku #59586000152
MFG #140DAI75300
Attributes
| Number of Inputs: | 32 |
| Signal Range: | 230 V AC |
| Amperage Rating: | 11.5 to 9.7 mA |
| Number of Outputs: | 32 |
| Voltage Rating: | 230 V AC |
| Power Rating: | 5 W |
- Modicon® Quantum™ Automation Platform Applications
- RoHS Compliant|CE Marked|CSA C22.2 No. 142|cUL Listed|FM Class 1 Div 2|UL 508|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65Warnings.ca.gov
- 4 groups of 8 channels
- 2-input word addressing requirement
- 26500 Ohm at 57 to 63 Hz/31800 Ohm at 47 to 53 Hz capacitive input impedance
- 47 to 63 Hz network frequency
- 4.9 to 0.75 ms x line cycle On/Off, 7.3 to 12.3 ms On/Off response time
- 1780 VRMs for 1 min isolation between channel and bus
- 250 mA bus current
- 4 kV contacts conforming to IEC 801-2, 8 kV on air conforming to IEC 801-2 resistance to electrostatic discharge
- 10 V/m 80 to 2000 MHz conforming to IEC 801-3 resistance to electromagnetic fields
- 95% without condensation relative humidity
- Standard module format
- 264 V continuous/312 V 10 s/400 V 1 cycle absolute maximum input
- Concept, ProWORX 32 and Unity Pro software
- -40 to 185 deg F storage temperature
- 1-LED green bus communication is present (active), 1-LED red external fault detected (F), 32-LED green input status
