ABB CA4-40E Auxiliary Contact Block, 24 to 690 VAC, 6 A, 4NO Contacts
Sku #47152313014
MFG #CA4-40E
Attributes
| Voltage Rating: | 24 to 690 V AC |
| Frequency Rating: | 50/60 Hz |
| Mounting Type: | DIN Rail |
| Amperage Rating: | 6 A |
| Number of Contacts: | 4NO |
| Suitable For Use With: | Model AF26-30-00 to AF38-30-00/AF09-40-00 to AF38-40-00 and AF09-22-00 to AF38-22-00 Across The Line Block Contactors |
- Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
- Front mounted instantaneous auxiliary contact block with 4NO contacts
- 4 A at 220/240 V, 6 A at 24/127 V, 2 A at 500 V, 2 A at 690 V, 3 A at 400/440 V rated operational current AC-15 and 0.55 A/69 W at 125 V, 6 A/144 W at 24 V, 0.27 A/68 W at 250 V, 2.8 A/134 W at 48 V, 1 A/72 W at 72 V, 0.55 A/60 W at 110 V, 0.27 A/60 W at 220 V, 0.15 A/60 W at 400 V, 0.13 A/65 W at 500 V, 0.1 A/60 W at 600 V rated operational current DC-13
- RoHs, CSA, cUL, CE, GOST
