ABB AF09ZB-22-00RT-23 DC Operated Low Coil Consumption IEC Contactor With Ring Tongue Ferrule, 100 to 250 V AC/DC V Coil, 25 A, 2NO-2NC Contact, 4 Poles
Sku #47152312973
MFG #AF09ZB-22-00RT-23
Attributes
| Type: | DC Operated Low Coil Consumption |
| Maximum Load Current: | 25 A |
| Number of Poles: | 4 |
| Coil Voltage: | 100 to 250 V AC/DC |
| Coil Power Rating: | 2.2/4/5.5 kW |
| Frequency Rating: | 50/60 Hz |
- For controlling non-inductive or slightly inductive loads and generally for controlling power circuits up to690VAC and440VDC
- Designed in accordance to the applicable parts of IEC60077and EN50155standard
- Shocks and vibration withstand conforming to IEC61373(category1, class B)
- Fire and smoke safety compliance to European standard EN 45545 (HL2, HL3 hazard levels)
- Electronic coil interface accepting a wide DC control voltage range (0.85 Ucminimum to 1.1Ucmaximum according to IEC60947-4-1) including several Uc control voltages (0.7 to 1.25Uc according to IEC60077) used for battery supply
- Built-in surge suppression
- Side by side mounting without restriction from -40to 70 deg C
- 2.2 kW at 220 to 230 to 240 V, 4 kW at 380 to 400/415/440 V, 5.5 kW at 500/690 V
- 25 A at 600 V UL/CSA, 1-phase 690 V IEC
- IEC 60947-1|IEC 60947-4-1|EN 60947-1|EN 60947-4-1|UL 508|CSA C22.2 File No. 14|IEC 60077|EN 50155|IEC 61373|EN 45545
