ABB AF38ZB-30-00RT-21 DC Operated Low Coil Consumption IEC Contactor, 24 to 60 V AC, 20 to 60 V DC V Coil, 34 A, 3NO Contact, 3 Poles
Sku #47152312911
MFG #AF38ZB-30-00RT-21
Attributes
| Type: | DC Operated Low Coil Consumption |
| Maximum Load Current: | 34 A |
| Number of Poles: | 3 |
| Coil Voltage: | 24 to 60 V AC, 20 to 60 V DC |
| Coil Power Rating: | 18.5 kW, 25 hp, 30 hp |
| Frequency Rating: | 50/60 Hz |
- Designed in accordance to the applicable parts of IEC60077and EN50155standard
- Shocks and vibration withstand conforming to IEC61373(category1, class B)
- Fire and smoke safety compliance to European standard EN 45545 (HL2, HL3 hazard levels)
- Electronic coil interface accepting a wide DC control voltage range (0.85 Ucminimum to 1.1Ucmaximum according to IEC60947-4-1) including several Uc control voltages (0.7 to 1.25Uc according to IEC60077) used for battery supply
- Built-in surge suppression
- Side by side mounting without restriction from -40 to 70 deg C
- 18.5 kW at 3-phase 400 V IEC, 25 hp at 440 to 480 VAC, 30 hp at 550 to 600 VAC
- For controlling3-phase motors and power circuits up to690VAC and220VDC
- IEC 60947-4-1|CSA 22.2 60947-4-1|IEC 60077|EN 50155|IEC 61373|EN 45545
