ABB LS35P11B11 LS Series Limit Switch, 600/690 V AC, 2.8/10 A, Plunger Actuator, 1NO-1NC Contact
Sku #47152261007
MFG #LS35P11B11
Attributes
| Series: | LS Series |
| Amperage Rating: | 2.8/10 A |
| Contact Configuration: | 1NO-1NC |
| Voltage Rating: | 600/690 V AC |
| Frequency Rating: | 50/60 Hz |
| Closed Contact Resistance: | 25 MOhm |
- RoHs, CSA, cUL, CE, GOST
- 130 VAC at 5.5 A, 230 VAC at 3.1 A, 240 VAC at 3 A, 24 VAC at 10 A, 400 VAC at 1.8 A rated operational current
- 110 VDC at 0.6/66 A, 24 VDC at 2.8/67.2 A, 250 VDC at 0.27/67.5 A
- Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
