Schneider Electric TSXDSY16S5 TSX Discrete Output Module, 16 inputs
Sku #38911087624
MFG #TSXDSY16S5
Attributes
| Type: | Discrete Output Module |
| Number of Inputs: | 16 |
| Amperage Rating: | 1 A |
| Series: | TSX |
| Voltage Rating: | 48 to 240 V AC |
| Power Rating: | 0.85,1 W |
- IEC languages as standard: LD, ST, FBD, SFC, IL. High performance CPUs with 37 ns per instruction and up to 7 Mb of programme
- High-level multitasking system
- A compact system (very high density modules) particularly at ease in extended architectures (distribution of 16 racks in real time without repeater)
- An extensive catalogue of application-specific modules (safety, reflex processing, counter, position control, motion, weighing, data storage)
- All Ethernet TCP/IP Transparent Ready services: IO scanning, Global Data, Web server, e-mail messaging, direct access to databases, TCP Open, Network Time Protocol, etc
- Numerous built-in ports: USB port, Ethernet TCP/IP port with Web server, CANopen or FIP master port, Modbus serial port
- The widest connectivity offer on the market:AS-Interface, Modbus Plus, INTERBUS or PROFIBUS DP
- Standard module format
- 0 to 6561.68 ft (0 to 2000 m) operating altitude
- TC protective treatment
- 1 A current per channel
- 12 A maximum current per module
- < 10 ms (activation)< 10 ms (deactivation) response time
- Ge-Mov output overvoltage protection
- 5 A, integrated fuse fast blow output overload protection
- 5 A, integrated fuse fast blow short-circuit protection
- (0.85 W + 1 W x No of outputs x current per module) power dissipation
- 2000 V 50/60 Hz 60 s dielectric strength
